Rent The Optosplitter an optically-isolated amplified splitter that allows the addition of four branches to a DMX data link.

The truth is, a light is just a light. It's the service that makes some lights out-shine the rest. And service is what we pride ourselves on.  Our industry veterans maintain the brands in demand for lighting units, dimmers, control systems, moving lights, and associated rigging.

We provide a variety of services that are specifically tailored to your needs. Our experienced staff will work closely with you to insure a successful event. We specialize in basic meetings, corporate meetings and special events.

We guarantee to help you communicate more effectively. Let us show you how to make a positive impact that gets results.

Any meeting or small gathering that requires Audio-Visual equipment and lighting to help articulate the message of the speaker.

Large scale events that require Audio-Visual equipment and support. To entertain and support a theme event, or a larger meeting setting. The most common Corporate Event could be national sales meetings, new product launches, corporate stockholder meetings.

We are a full service audio, visual, video, lighting, staging, and computer rental company.  Serving clients nationally, we offer one of the most comprehensive inventories in the industry for small businesses events, conventions, tradeshows, expositions, event planners, training seminars, and live entertainment shows. With the latest in technology from leading manufacturers, we ensure your event will be a total success.  Rent Tradeshow AV Equipment  Call 866-858-1174 for information

Optosplitter SPECIFICATIONS   Description The Optosplitter is an optically-isolated amplified splitter that allows the addition of four branches to a DMX data link. The amplification it provides allows a DMX link to be extended over the maximum length specified by the DMX-512 standard. Each branch is managed as an independent DMX data link and optical isolation ensures that a failure on one branch will have no effect on the other branches. Up to 32 fixtures can be attached to each branch. Several splitter amplifiers can be used on the same link if additional branches are required. Physical Length: 293 mm (11.5 in) Width: 108 mm (4.25 in) Height: 49 mm (1.9 in) Weight: 1.4 kg (3.1 lb) Construction Housing: steel Finish: electrostatic powder coating Color: black AC Supply Power supply settings: 115/230 V, switch selectable AC frequency: 50 - 60 Hz Connections Input: 3 pin XLR male Throughput (output with no amplification): 3 pin XLR female Outputs (amplified and optically isolated): 4 x 3-pin XLR female Data link Electrical standard: EIA-485 Cable type: shielded twisted pair Cable gauge: 22 or 24 AWG Cable impedance: 120 ohms Maximum length per branch (22 AWG): 500 m (1640 ft) Maximum length per branch (24 AWG): 300 m (1000 ft) Maximum load per branch: 32 fixtures Included items     Sample project specification General The device shall be an optically isolated splitter amplifier that enables the addition of four branches to a DMX data link. The device shall enable a DMX link to be extended over the maximum length specified by the DMX-512 standard. Housing The device shall have a steel housing with a black electrostatic powder coating. It shall provide holes for the attachment of mounting hardware. Installation The device shall operate in any orientation. It shall be able to be mounted in a fixed installation. Electrical The device shall provide an selectable power supply for operation on 50 or 60 Hz supplies at 115 or 230 volts. The device shall be electrically grounded. Connections The device shall provide a single DMX input, a single un-amplified DMX output, and 4 amplified and optically isolated DMX output connections. The device shall support DMX data links that comply with electrical standard EIA-485, using shielded twisted pair cables with a gauge of 22 or 24 AWG, and an impedance of 120 ohms. Performance The device shall support up to 32 fixtures on each of four amplified and optically isolated DMX branches. The device shall support cable-type 22-AWG branches of up to 500 m (1640 ft) in length, or cable-type 24-AWG branches of up to 300 m (1000 ft) in length. It shall be able to operate together with additional splitter amplifiers on the same data link. Physical The device shall have the following physical dimensions (LxWxH): 293 x 108 x 49 mm (11.5 x 4.25 x 1.9 in). The device shall weigh: 1.4 kg (3.1 lbs.)

  Rent Tradeshow AV Equipment  Call 866-858-1174 for information

Staging/Lighting/Trussing
		Black Pipe and Drape - includes hardware (priced per ft)
		Tomcat 12X12X8 Box Truss
		Tomcat 20X20X10 Box Truss
		Trooperette Follow Spotlight
		Par 64 Specials
		Martin Moving Lights MAC 550 Moving Light Rentals
		Leprecon lighting board
		Par 64 Specials
		Source 4 Ellipsoidals
		Dimmer Packs
		Lighting Controller - 12 Channel
		Ultimate Light Stands (8 lights max.)
		Standing Oak Lectern
		RTS Base Station w/ Headset
		Additional Headset
		Language Interpretation System -2 headsets
		Additional Interpretation Headsets
		Staging (Please call for sizes) Sets

  Rent Tradeshow AV Equipment  Call 866-858-1174 for information

Intelligent Lighting: Martin Macs (including tons of 2K's and 550's),VariLites, Coemar Cycs, Studio Spots, Studio Colors, Intellabeams, Cyberlights, Trackspots
Truss: 8' Double-Hung PreRig, Heavy Duty Truss, Genie Towers, Slings, Shackles Various Lifts and stands
Dimming and Control: We have literally thousands of channels of State of the Art Dimming and Control equipment including the new Jands VISTA, full line ETC, Grand MA's, Whole Hogs Versions 2 and 3, CAE, MA Scan Commander, and more..
Specials: Include a variety of the latest LED Fixtures, scrollers and color changers, A huge selection of Rosco, High End Systems, LeMaitre, and City Theatrical fog machines to create a variety of smoke effects - from low lying “graveyard” fog to a misty haze. Bubble machines, Mirror balls and Rope Lights and Chaser controls for your party or event needs.
Follow Spots: Feature Strong Xenon Super Trouper, Lycian Super Arc long and short throw units, Lycian Starklite 1271 (with short medium and long throw lenses), Lots of Lycian Super Club Spots and 1275's, Altman Comets and 1000Q’s.
Miscellaneous Stuff: We have Headsets, miles and miles of load and multi cable as well as gobs of heavy duty line side distribution equipment and cables.
Lighting and Grip for Film, TV and Still: Prepackaged Kits, HMI Pars in 1200 and 2500 watt configuration, stands, Fresnels, Open Face Broads,
And Of Course: All the Ellipsoidals, Source Fours, Fresnels, Border lights, Scoops, Pars you need - complete with all the hanging hardware you require.
We have avariety of standard lighting, video and audio packages to suit a variety of applications.

The MAC 550 features unprecedented illumination for a 400W
fixture along with astounding graphics and animation.
Motorized zoom (14 to 30 degrees)
Gobo animation wheel with full movement / direction control
2 x 8 slot replaceable color wheels, plus open
1 x 6 position rotating gobo wheel, plus open
1 x 9 position static gobo wheel, plus open
Rotating Replaceable Prism
Dimmer / Shutter
Remote Focus
Motorized Iris
540 degrees Pan x 246 degrees Tilt

Stage and Set
Design Rentals

PC Computer
Rentals

Computer Kiosk
 Rentals


Translation
Systems


There's more to rigging than wire rope and shackles! Safety requires that riggers thoroughly understand both equipment and the engineering principles. Relying on intuition for rigging is foolish and risky. To save lives, reduce liability, and comply with OSHA, riggers must be trained, knowledgeable, and competent. Safe rigging is not guesswork.  Rigging Seminars
